Special point:

universal flange, tapered antenna.

It should be used:

it is mainly used for measuring the height of solids and blocks.

(e.g. : original bunker, powder bunker, coke level, etc.)

Maximum range: 30 m

Process connection: universal flange

The process temperature: - 40 ~ 250 ℃

Process pressure: atmospheric pressure

Fine degrees: ±15 mm

Reduplication: ± 2mm

Frequency range: 6.8GHz

Signal output: (4~20)mA/HART agreement (24V DC two-wire system/four-wire system)

(4~20)mA/HART agreement (220V AC four-wire system)

Explosion-proof grade: Exia IIC T6 Ga

Protection class: IP 67
